Built for the gamers

AMD Radeon™ RX 6600 graphics cards deliver serious 1080p gaming and ultra-high frame rates. Get up to 28 high-performance compute units, groundbreaking AMD Infinity Cache, and up to 8GB of dedicated GDDR6 memory. Experience the next gen of gaming performance with AMD Smart Access Memory technology when you pair an AMD Radeon™ RX 6000 Series graphics card with an AMD Ryzen™ 5000 Series desktop processor.

Specifications

Bus Type: PCI-E 4.0 @ 8x

Clock Speeds:
Base clock Up to: 1626 MHz
Game Clock Up To: 2044 MHz*
Boost clock Up to: 2491MHz**

Stream Processors:  1792
Compute Units: 28
Memory Bus: 128 bit
Memory Clock: 14 Gbps
Memory Size: 8 GB
Memory Type: GDDR6
Card Profile:  Dual Slot
Thermal Solution: Dual Fan

KEY Features

Advanced 7nm GPU
PCI Express 4.0 Support
Radeon Image Sharpening
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
AMD Virtual Super Resolution (VSR)
AMD Relive
AMD FreeSync 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity multi-display technology
AMD Radeon Adrenalin Software
AMD WattMan
HDMI 2.0b
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
Up to 5 displays supported, (may require the use of MST Hubs)
OpenGL 4.5 Support
OpenCL Support

Outputs

DisplayPort: 1.4 with DSC
HDMI™: 2.1 VRR and FRL
Output : Display Port 3
Output: HDMI 1

Minimum Requirements

External Power: 1x PCI-E 8 pin connections
Minimum Power Supply Requirement: 550 watt
XFX Recommended Power Supply: XFX 650W PSU
